FXPT22200
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Amphenol 5.08mm Pitch Straight Barrier Strip, Terminal Blocks with Screw Down Termination, Cable Mount, 22 Way
PDF
/
Inventory: 6627
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Width 17.52mm
Length 118.61mm
Technical
Number of Positions Per Level 22
Wire Strip Length 7.87mm
Plug Wire Entry 90°
Positions Per Level 11
Torque - Screw 1.13 Nm (10.0 Lb-In)
Current - UL 15A
Wire Gauge or Range - AWG 12-26 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 26 AWG
Current 15A
Number of Levels 2
Number of Circuits 22
Voltage 300V
Housing Color Black
Number of Contacts 22
Termination Style Screw with Captive Plate
Current Rating 15A
Insulation Height 0.690 17.53mm
Depth 29.05mm
Orientation Straight
Pitch 0.200 5.08mm
Voltage - Rated 300V
Gender Female
Number of Rows 1
Color Black
Number of Positions 22
Type Plug, Female Sockets
Termination Screw
Part Status Active
Feature Retention Latches (Non-Wire Side)
Series FXP FlexiPlug?
Published 2008
Packaging Bulk
Operating Temperature 105°C
Physical
Housing Material Polyphenylene Oxide (PPO)
Material PPO
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
