ELXT04600
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Header
PDF
/
Inventory: 6110
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA46), Nylon 4/6
Technical
Operating Temperature 125°C
Packaging Tray
Published 2006
Series ELXT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Female Sockets
Number of Positions 4
Color Black
Number of Rows 1
Pitch 0.138 3.50mm
Orientation Straight
Insulation Height 0.738 18.75mm
Termination Style Screw - Rising Cage Clamp
Number of Contacts 4
Housing Color Black
Voltage 300V
Number of Circuits 4
Number of Levels 1
Current 12A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 16 AWG
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 16-28 AWG
Current - UL 12A
Torque - Screw 0.25 Nm (2.2 Lb-In)
Positions Per Level 4
Plug Wire Entry 270°
Wire Strip Length 6.35mm
Number of Positions Per Level 4
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
