ELXT02500

Amphenol PCD
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Terminal Block Header
PDF
/
Inventory: 9262
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Technical

Number of Positions Per Level 2
Wire Strip Length 6.35mm
Plug Wire Entry 90°
Positions Per Level 2
Torque - Screw 0.25 Nm (2.2 Lb-In)
Current - UL 12A
Wire Gauge or Range - AWG 16-28 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 28 AWG
Current 12A
Number of Levels 1
Number of Circuits 2
Voltage 300V
Housing Color Black
Number of Contacts 2
Termination Style Screw - Rising Cage Clamp
Insulation Height 0.738 18.75mm
Orientation Straight
Pitch 0.138 3.50mm
Gender Female
Number of Rows 1
Color Black
Number of Positions 2
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ELXT
Published 2006
Packaging Tray
Operating Temperature 125°C

Physical

Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 8 Weeks
