ELXP05100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Plug
PDF
/
Inventory: 7588
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Number of Positions Per Level 5
Wire Strip Length 6.35mm
Plug Wire Entry 180°
Positions Per Level 5
Torque - Screw 0.25 Nm (2.2 Lb-In)
Current - UL 12A
Wire Gauge or Range - AWG 16-28 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 28 AWG
Current 12A
Number of Levels 1
Voltage 300V
Termination Style Screw - Rising Cage Clamp
Insulation Height 0.437 11.10mm
Pitch 0.138 3.50mm
Color Black
Number of Positions 5
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ELXP
Published 2012
Packaging Tray
Operating Temperature 125°C
Physical
Housing Material Polyamide (PA46), Nylon 4/6
Number of Pins 5
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
