ELXH06500

Amphenol PCD
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Pluggable Terminal Blocks 6P 3.5mm Mini Header Vertical 15A 300V
PDF
/
Inventory: 955
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Width 6.93mm
Length 21.71mm
Height 9.14mm

Technical

Number of Positions Per Level 6
Header Orientation Vertical
Safety Approval UL; CSA
Number of Ways 6
Number of Decks 1
Contact Mating Finish Tin
Current 12A
Number of Levels 1
Max Current Rating 12A
Contact Tail Length 0.138 3.50mm
Voltage 300V
Insulation Resistance 105mOhm
Termination Style Solder
Current Rating 15A
Insulation Height 0.360 9.14mm
Depth 6.93mm
Pitch 0.138 3.50mm
Voltage - Rated 300V
Gender Male
Number of Rows 1
Color Black
Type Header, Male Pins, Shrouded (4 Side)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ELXH
Published 2006
Packaging Tray
Operating Temperature 125°C

Physical

Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass

Supply Chain

Factory Lead Time 8 Weeks
