ELVP16100E

Amphenol PCD
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Terminal Block Header
PDF
/
Inventory: 1972
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Technical

Wire Strip Length 6.35mm
Plug Wire Entry 180°
Positions Per Level 16
Torque - Screw 0.25 Nm (2.2 Lb-In)
Current - UL 12A
Wire Gauge or Range - AWG 16-28 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Number of Levels 1
Number of Circuits 16
Housing Color Black
Number of Contacts 16
Termination Style Screw - Rising Cage Clamp
Insulation Height 0.437 11.10mm
Orientation Right Angle
Pitch 0.150 3.81mm
Gender Female
Number of Rows 1
Color Black
Number of Positions 16
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Mating Flange
Series ELVP
Packaging Bulk
Operating Temperature 125°C

Physical

Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Free Hanging (In-Line)
Mount Cable
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 8 Weeks
