ELVP09100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TERM BLOCK PLUG 9POS STR 3.81MM
PDF
/
Inventory: 5551
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA46), Nylon 4/6
Technical
Operating Temperature 125°C
Packaging Tray
Published 2008
Series ELVP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Female Sockets
Number of Positions 9
Color Black
Number of Rows 1
Pitch 0.150 3.81mm
Orientation Right Angle
Insulation Height 0.437 11.10mm
Termination Style Screw - Rising Cage Clamp
Number of Contacts 9
Housing Color Black
Voltage 300V
Number of Circuits 9
Number of Levels 1
Current 12A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 16 AWG
Number of Poles 9
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 16-28 AWG
Current - UL 12A
Torque - Screw 0.25 Nm (2.2 Lb-In)
Positions Per Level 9
Plug Wire Entry 180°
Wire Strip Length 6.35mm
Number of Positions Per Level 9
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
