ELVP02100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Terminal Block F 2 POS 3.81mm Screw RA Cable Mount 12A
PDF
/
Inventory: 3054
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Length 7.62mm
Technical
Number of Positions Per Level 2
Wire Strip Length 6.35mm
Plug Wire Entry 180°
Positions Per Level 2
Torque - Screw 0.25 Nm (2.2 Lb-In)
Current - UL 12A
Wire Gauge or Range - AWG 16-28 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Number of Poles 2
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 28 AWG
Current 12A
Number of Levels 1
Max Current Rating 12A
Max Supply Voltage 300V
Voltage 300V
Termination Style Screw - Rising Cage Clamp
Insulation Height 0.437 11.10mm
Depth 18.38mm
Orientation Right Angle
Pitch 0.150 3.81mm
Number of Rows 1
Color Black
Number of Positions 2
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ELVP
Published 2008
Packaging Tray
Operating Temperature 125°C
Physical
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
