ELVH04500
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Wire to Board HDR 4 POS 3.81mm Solder ST Thru-Hole
PDF
/
Inventory: 8729
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA46), Nylon 4/6
Technical
Operating Temperature 125°C
Packaging Tray
Published 2006
Series ELVH
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 4
Color Black
Number of Rows 1
Pitch 0.150 3.81mm
Orientation Vertical
Depth 6.93mm
Insulation Height 0.360 9.14mm
Termination Style Solder
Number of Contacts 4
Housing Color Black
Voltage 300V
Contact Tail Length 0.138 3.50mm
Max Current Rating 12A
Number of Levels 1
Current 12A
Number of Poles 4
Contact Mating Finish Tin
Voltage - UL 300V
Current - UL 12A
Positions Per Level 4
Header Orientation Vertical
Number of Positions Per Level 4
Dimensions
Length 16.05mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
