ELVD28100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Header
PDF
/
Inventory: 4624
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA46), Nylon 4/6
Technical
Operating Temperature 125°C
Packaging Tray
Published 2012
Series ELVD
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 28
Color Black
Number of Rows 2
Pitch 0.150 3.81mm
Orientation Right Angle
Insulation Height 0.890 22.61mm
Termination Style Solder
Housing Color Black
Voltage 300V
Contact Tail Length 0.138 3.50mm
Max Current Rating 12A
Number of Levels 2
Current 12A
Contact Mating Finish Tin
Voltage - UL 300V
Current - UL 12A
Positions Per Level 14
Header Orientation 90°, Right Angle
Number of Positions Per Level 14
Dimensions
Length 54.15mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
