ELLP08110
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
ELLP RoHS Compliant 2011 Retention Latches (Non-Wire Side) Terminal Block Plug, Female Sockets 26AWG -40C~95C 15A 600V
PDF
/
Inventory: 8473
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyphenylene Oxide (PPO)
Technical
Operating Temperature -40°C~95°C
Packaging Tray
Published 2011
Series ELLP
Feature Retention Latches (Non-Wire Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Female Sockets
Number of Positions 8
Color Black
Pitch 0.394 10.00mm
Termination Style Screw - Rising Cage Clamp
Voltage 600V
Number of Levels 1
Current 15A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 12 AWG
Contact Mating Finish Nickel
Wire Gauge or Range - AWG 12-26 AWG
Torque - Screw 0.79 Nm (7.0 Lb-In)
Plug Wire Entry 180°
Wire Strip Length 7.87mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
