ELLK08210
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
ELLK RoHS Compliant 2011 Retention Latches (Non-Wire Side) Terminal Block Plug, Female Sockets 26AWG 105C 15A 600V
PDF
/
Inventory: 2580
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Wire Strip Length 7.87mm
Plug Wire Entry 45°
Torque - Screw 0.79 Nm (7.0 Lb-In)
Wire Gauge or Range - AWG 12-26 AWG
Contact Mating Finish Nickel
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 26 AWG
Current 15A
Number of Levels 1
Voltage 600V
Termination Style Screw - Rising Cage Clamp
Pitch 0.400 10.16mm
Color Black
Number of Positions 8
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Retention Latches (Non-Wire Side)
Series ELLK
Published 2011
Packaging Tray
Operating Temperature 105°C
Physical
Housing Material Polyphenylene Oxide (PPO)
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
