ELFP24110
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Plug
PDF
/
Inventory: 1898
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Length 120mm
Technical
Number of Positions Per Level 24
Wire Strip Length 7.87mm
Plug Wire Entry 180°
Positions Per Level 24
Torque - Screw 0.79 Nm (7.0 Lb-In)
Current - UL 15A
Wire Gauge or Range - AWG 12 AWG, 14-26 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 26 AWG
Current 15A
Number of Levels 1
Max Current Rating 15A
Max Supply Voltage 300V
Number of Circuits 24
Voltage 300V
Housing Color Black
Number of Contacts 24
Termination Style Screw - Rising Cage Clamp
Insulation Height 0.592 15.04mm
Depth 18.4mm
Orientation Right Angle
Pitch 0.197 5.00mm
Gender Female
Number of Rows 1
Color Black
Number of Positions 24
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Retention Latches (Non-Wire Side)
Series ELFP
Published 2006
Packaging Tray
Operating Temperature -40°C~95°C
Physical
Housing Material Polyphenylene Oxide (PPO)
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Lead, Tin
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
