ELFF15140

Amphenol PCD
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Conn Terminal Blocks F 15 POS 5mm Screw ST Cable Mount 15A
PDF
/
Inventory: 4676
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Technical

Number of Positions Per Level 15
Wire Strip Length 7.87mm 12.45mm
Plug Wire Entry 270°
Positions Per Level 15
Torque - Screw 0.79 Nm (7.0 Lb-In)
Current - UL 15A
Wire Gauge or Range - AWG 12 AWG, 14-26 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 26 AWG
Current 15A
Number of Levels 1
Number of Circuits 15
Voltage 300V
Housing Color Black
Number of Contacts 15
Termination Style Screw - Rising Cage Clamp
Insulation Height 1.218 30.94mm
Orientation Straight
Pitch 0.197 5.00mm
Gender Female
Number of Rows 1
Color Black
Number of Positions 15
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Retention Latches (Non-Wire Side)
Series ELFF
Published 2006
Packaging Tray
Operating Temperature 105°C

Physical

Housing Material Polyphenylene Oxide (PPO)
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 8 Weeks
