ELFF12130
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
ELFF RoHS Compliant Straight Retention Latches (Wire Side) Terminal Block Plug, Female Sockets 26AWG 105C 15A 300V
PDF
/
Inventory: 2980
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyphenylene Oxide (PPO)
Technical
Operating Temperature 105°C
Packaging Tray
Series ELFF
Feature Retention Latches (Wire Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Female Sockets
Number of Positions 12
Color Black
Number of Rows 1
Gender Female
Pitch 0.197 5.00mm
Orientation Straight
Insulation Height 1.218 30.94mm
Termination Style Screw - Rising Cage Clamp
Number of Contacts 12
Housing Color Black
Voltage 300V
Number of Circuits 12
Number of Levels 1
Current 15A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 14 AWG
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 12 AWG, 14-26 AWG
Current - UL 15A
Torque - Screw 0.79 Nm (7.0 Lb-In)
Positions Per Level 12
Plug Wire Entry 90°
Wire Strip Length 7.87mm 12.45mm
Number of Positions Per Level 12
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
