ELFF05220
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
ELFF RoHS Compliant 2006 Retention Latches (Non-Wire Side) Terminal Block Plug, Female Sockets 26AWG 105C 15A 300V
PDF
/
Buying Options
Total Price: USD $3.86
Unit Price: USD $3.864501
≥1 USD $3.864501
≥10 USD $3.645754
≥100 USD $3.439389
≥500 USD $3.244708
≥1000 USD $3.061043
Inventory: 9360
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Number of Positions Per Level 5
Wire Strip Length 7.87mm 12.45mm
Plug Wire Entry 270°
Positions Per Level 5
Torque - Screw 0.79 Nm (7.0 Lb-In)
Current - UL 15A
Wire Gauge or Range - AWG 12 AWG, 14-26 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 26 AWG
Current 15A
Number of Levels 1
Voltage 300V
Termination Style Screw - Rising Cage Clamp
Current Rating 15A
Insulation Height 1.217 30.91mm
Pitch 0.200 5.08mm
Voltage - Rated 300V
Color Black
Number of Positions 5
Type Plug, Female Sockets
Connector Type Screw
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Retention Latches (Non-Wire Side)
Series ELFF
Published 2006
Packaging Tray
Operating Temperature 105°C
Physical
Housing Material Polyphenylene Oxide (PPO)
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 8 Weeks
