ELFD28120
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Stackable Header HDR 28 POS 5mm Solder RA Thru-Hole
PDF
/
Inventory: 8094
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature 105°C
Packaging Tray
Published 2006
Series ELFD
Feature Interlocking (Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Header, Male Pins, Shrouded (2 Side)
Number of Positions 28
Color Black
Number of Rows 2
Gender Male
Pitch 0.197 5.00mm
Orientation Right Angle
Insulation Height 0.900 22.86mm
Termination Style Solder
Number of Contacts 28
Housing Color Black
Voltage 300V
Contact Tail Length 0.155 3.94mm
Max Current Rating 15A
Number of Levels 2
Current 15A
Contact Mating Finish Tin
Voltage - UL 300V
Current - UL 15A
Positions Per Level 14
Header Orientation 90°, Right Angle
Number of Positions Per Level 14
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
