ELFD18160
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
ELFD RoHS Compliant 2006 Vertical Terminal Block Header, Male Pins, Shrouded (2 Side) Vertical 15A 300V 0.197 5.00mm
PDF
/
Buying Options
Total Price: USD $33.52
Unit Price: USD $33.515921
≥1 USD $33.515921
≥10 USD $31.61879
≥100 USD $29.829047
≥500 USD $28.140608
≥1000 USD $26.547742
Inventory: 1160
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Technical
Number of Positions Per Level 9
Header Orientation Vertical
Positions Per Level 9
Current - UL 15A
Voltage - UL 300V
Contact Mating Finish Tin
Current 15A
Number of Levels 2
Max Current Rating 15A
Contact Tail Length 0.155 3.94mm
Voltage 300V
Housing Color Black
Number of Contacts 18
Termination Style Solder
Orientation Vertical
Pitch 0.197 5.00mm
Gender Male
Number of Rows 2
Color Black
Number of Positions 18
Type Header, Male Pins, Shrouded (2 Side)
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Interlocking (Side)
Series ELFD
Published 2006
Packaging Tray
Operating Temperature 105°C
Physical
Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
