ELFB17280
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks Ver Board Mnt Plug .2 in 17 Pos.
PDF
/
Inventory: 3910
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Header Orientation Vertical
Safety Approval UL; VDE; CSA
Number of Ways 17
Number of Decks 1
Contact Mating Finish Tin
Current 15A
Number of Levels 1
Max Current Rating 15A
Contact Tail Length 0.138 3.50mm
Voltage 300V
Termination Style Solder
Reach Compliance Code unknown
Insulation Height 0.750 19.05mm
Depth 19.05mm
Pitch 0.200 5.08mm
HTS Code 8536.69.40.40
Additional Feature NYLON 46, UL: 94V-0
Number of Rows 2
Color Black
Number of Positions 17
Type Header, Female Sockets
ECCN Code EAR99
Part Status Active
Feature Interlocking (Side), Retention Latches
Series ELFB
Published 2006
Packaging Bulk
Operating Temperature 125°C
Physical
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 8 Weeks
