ELFB14230
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks Hor Board Mnt Plug .2 in 14 Pos.
PDF
/
Inventory: 4348
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Phosphor Bronze
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA46), Nylon 4/6
Technical
Operating Temperature 125°C
Packaging Bulk
Published 2006
Series ELFB
Feature Interlocking (Side), Retention Latches
Part Status Active
Termination Solder
Type Header, Female Sockets
Number of Positions 14
Color Black
Number of Rows 1
Pitch 0.200 5.08mm
Orientation Right Angle
Depth 9.93mm
Insulation Height 0.391 9.93mm
Termination Style Solder
Housing Color Black
Voltage 300V
Contact Tail Length 0.123 3.12mm
Max Current Rating 15A
Number of Levels 1
Current 15A
Contact Mating Finish Tin
Voltage - UL 300V
Current - UL 15A
Positions Per Level 14
Header Orientation 90°, Right Angle
Number of Positions Per Level 14
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
