ELFA34150
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Socket
PDF
/
Inventory: 7340
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length 87mm
Technical
Number of Positions Per Level 17
Header Orientation Vertical
Positions Per Level 17
Current - UL 15A
Voltage - UL 300V
Contact Mating Finish Tin
Current 15A
Number of Levels 2
Max Current Rating 15A
Max Voltage Rating (AC) 300V
Contact Tail Length 0.145 3.68mm
Voltage 300V
Housing Color Black
Termination Style Solder
Insulation Height 0.879 22.33mm
Depth 28.44mm
Orientation Vertical
Pitch 0.197 5.00mm
Number of Rows 2
Color Black
Number of Positions 34
Type Header, Male Pins, Shrouded (4 Side)
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ELFA
Published 2006
Packaging Tray
Operating Temperature 125°C
Physical
Housing Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
