ELFA3225G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
ELFA RoHS Compliant Tin Brass Terminal Block Header, Male Pins, Shrouded (4 Side) Vertical 15A 300V 0.885 22.48mm
PDF
/
Inventory: 8812
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Header Orientation Vertical
Positions Per Level 16
Current - UL 15A
Voltage - UL 300V
Contact Mating Finish Tin
Number of Levels 2
Contact Tail Length 0.145 3.68mm
Termination Style Solder
Insulation Height 0.885 22.48mm
Pitch 0.200 5.08mm
Color Green
Number of Positions 32
Type Header, Male Pins, Shrouded (4 Side)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ELFA
Packaging Bulk
Operating Temperature 125°C
Physical
Housing Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Vertical
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
