ELFA2811G

Amphenol PCD
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Terminal Block Header
PDF
/
Inventory: 7853
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Technical

Header Orientation 90°, Right Angle
Positions Per Level 14
Current - UL 15A
Voltage - UL 300V
Contact Mating Finish Tin
Number of Levels 2
Contact Tail Length 0.155 3.94mm
Termination Style Solder
Insulation Height 1.107 28.12mm
Pitch 0.197 5.00mm
Color Green
Number of Positions 28
Type Header, Male Pins, Shrouded (4 Side)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ELFA
Packaging Bulk
Operating Temperature 125°C

Physical

Housing Material Polyamide (PA), Nylon
Mounting Type Through Hole
Contact Material Brass

Supply Chain

Factory Lead Time 8 Weeks
