ELFA18210
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Plug
PDF
/
Inventory: 5173
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Technical
Operating Temperature 125°C
Packaging Tray
Published 2006
Series ELFA
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 18
Color Black
Number of Rows 2
Pitch 0.200 5.08mm
Orientation Right Angle
Depth 22.47mm
Insulation Height 1.120 28.45mm
Termination Style Solder
Housing Color Black
Voltage 300V
Contact Tail Length 0.155 3.94mm
Max Voltage Rating (AC) 300V
Max Current Rating 15A
Number of Levels 2
Current 15A
Contact Mating Finish Tin
Voltage - UL 300V
Current - UL 15A
Positions Per Level 9
Header Orientation 90°, Right Angle
Number of Positions Per Level 9
Dimensions
Length 47.72mm
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
