ELFA1811G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
ELFA RoHS Compliant Tin Brass Terminal Block Header, Male Pins, Shrouded (4 Side) 90° Right Angle 15A 300V 1.107 28.12mm
PDF
/
Inventory: 6939
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Brass
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Technical
Operating Temperature 125°C
Packaging Bulk
Series ELFA
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 18
Color Green
Pitch 0.197 5.00mm
Insulation Height 1.107 28.12mm
Termination Style Solder
Contact Tail Length 0.155 3.94mm
Number of Levels 2
Contact Mating Finish Tin
Voltage - UL 300V
Current - UL 15A
Positions Per Level 9
Header Orientation 90°, Right Angle
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
