VM1855000000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
VM ROHS3Compliant Retention Latches (Non-Wire Side) Tin Terminal Block Plug, Female Sockets 12-22AWG -40C~115C 20A 300V
PDF
/
Inventory: 8986
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Screw Size M2.5
Wire Strip Length 6-7mm
Wire Gauge or Range - mm2 0.34-2.5mm2
Plug Wire Entry 180°
Torque - Screw 0.4 Nm (3.5 Lb-In)
Current - UL 20A
Wire Gauge or Range - AWG 12-22 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Number of Levels 1
Termination Style Screw - Pressure Clip
Insulation Height 0.591 15.00mm
Pitch 0.200 5.08mm
Color Black
Number of Positions 18
Type Plug, Female Sockets
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Retention Latches (Non-Wire Side)
Series VM
Packaging Bulk
Operating Temperature -40°C~115°C
Physical
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Contact Material Copper
Supply Chain
Factory Lead Time 10 Weeks
