V71811510000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
V7 ROHS3Compliant Tin Phosphor Bronze Terminal Block Header, Female Sockets 90° Right Angle 4A 300V 0.260 6.60mm
PDF
/
Inventory: 8106
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Housing Material Thermoplastic
Technical
Operating Temperature -40°C~115°C
Packaging Bulk
Series V7
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Header, Female Sockets
Number of Positions 18
Color Green
Pitch 0.138 3.50mm
Insulation Height 0.260 6.60mm
Termination Style Solder
Contact Tail Length 0.134 3.40mm
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Current - UL 4A
Header Orientation 90°, Right Angle
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
