V50551510000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
V5 ROHS3Compliant Mounting Flange Tin Terminal Block Receptacle, Male Pins 12-30AWG -40C~115C 12A 300V
PDF
/
Inventory: 9484
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Brass
Mounting Type Board Mount
Housing Material Thermoplastic
Technical
Operating Temperature -40°C~115°C
Packaging Bulk
Series V5
Feature Mounting Flange
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Receptacle, Male Pins
Number of Positions 5
Color Green
Pitch 0.200 5.08mm
Insulation Height 0.709 18.00mm
Termination Style Screw - Leaf Spring, Wire Guard
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 12-30 AWG
Current - UL 12A
Torque - Screw 0.5 Nm (4.4 Lb-In)
Wire Strip Length 6-7mm
Screw Size M3
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
