TY1201000000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TY ROHS3Compliant Tin M2.6 Terminal Block Plug for Unshrouded Header 14-26AWG -40C~115C 10A 300V
PDF
/
Inventory: 6934
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Screw Size M2.6
Wire Strip Length 6-7mm
Wire Gauge or Range - mm2 0.2-2.5mm2
Plug Wire Entry 90°
Torque - Screw 0.4 Nm (3.5 Lb-In)
Current - UL 10A
Wire Gauge or Range - AWG 14-26 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Number of Levels 1
Termination Style Screw - Leaf Spring, Wire Guard
Insulation Height 0.492 12.50mm
Pitch 0.197 5.00mm
Color Black
Number of Positions 12
Type Plug for Unshrouded Header
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TY
Packaging Bulk
Operating Temperature -40°C~115°C
Physical
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 10 Weeks
