TS23315D0000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TS ROHS3Compliant Mating Flange Tin Terminal Block Plug, Female Sockets 16-28AWG -40C~115C 8A 300V
PDF
/
Inventory: 5735
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Screw Size M2
Wire Strip Length 6-7mm
Wire Gauge or Range - mm2 1.5mm2
Plug Wire Entry 270°
Torque - Screw 0.2 Nm (1.7 Lb-In)
Current - UL 8A
Wire Gauge or Range - AWG 16-28 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Number of Levels 1
Termination Style Screw - Leaf Spring, Wire Guard
Insulation Height 0.752 19.10mm
Pitch 0.150 3.81mm
Color Green
Number of Positions 23
Type Plug, Female Sockets
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Mating Flange
Series TS
Packaging Bulk
Operating Temperature -40°C~115°C
Physical
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 10 Weeks
