TS16118D0000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TS ROHS3Compliant Mating Flange Tin Terminal Block Plug, Female Sockets 16-28AWG -40C~115C 8A 300V
PDF
/
Buying Options
Total Price: USD $5.26
Unit Price: USD $5.262103
≥1 USD $5.262103
≥200 USD $2.10064
≥500 USD $2.029743
≥1000 USD $1.995608
Inventory: 1140
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Technical
Operating Temperature -40°C~115°C
Packaging Bulk
Series TS
Feature Mating Flange
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug, Female Sockets
Number of Positions 16
Color Gray
Pitch 0.138 3.50mm
Insulation Height 0.760 19.30mm
Termination Style Screw - Leaf Spring, Wire Guard
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 16-28 AWG
Current - UL 8A
Torque - Screw 0.2 Nm (1.7 Lb-In)
Plug Wire Entry 270°
Wire Gauge or Range - mm2 1.5mm2
Wire Strip Length 6-7mm
Screw Size M2
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
