TJ0571000000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TJ ROHS3Compliant Retention Latches (Non-Wire Side) Tin Terminal Block Plug, Female Sockets 12-24AWG -40C~115C 20A 300V
PDF
/
Buying Options
Total Price: USD $1.84
Unit Price: USD $1.843312
≥1 USD $1.843312
≥200 USD $0.735224
≥500 USD $0.711592
≥1000 USD $0.699776
Inventory: 1073
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Technical
Operating Temperature -40°C~115°C
Packaging Bulk
Series TJ
Feature Retention Latches (Non-Wire Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug, Female Sockets
Number of Positions 5
Color Black
Pitch 0.197 5.00mm
Insulation Height 0.594 15.09mm
Termination Style Screw
Number of Levels 1
Contact Mating Finish Tin
Wire Gauge or Range - AWG 12-24 AWG
Voltage - IEC 300V
Torque - Screw 0.56 Nm (5.0 Lb-In)
Plug Wire Entry 180°
Wire Gauge or Range - mm2 0.34-2.5mm2
Wire Strip Length 7-8mm
Current - IEC 20A
Screw Size M3
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
