TH1901600000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TH ROHS3Compliant Interlocking (Side) M2.6 Terminal Block Plug for Unshrouded Header 14-22AWG -40C~115C 15A 300V
PDF
/
Inventory: 4397
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Screw Size M2.6
Wire Strip Length 5-6mm
Wire Gauge or Range - mm2 0.34-1.5mm2
Plug Wire Entry 90°
Torque - Screw 0.4 Nm (3.5 Lb-In)
Current - UL 15A
Wire Gauge or Range - AWG 14-22 AWG
Voltage - UL 300V
Number of Levels 1
Termination Style Screw - Leaf Spring, Wire Guard
Insulation Height 0.433 11.00mm
Pitch 0.197 5.00mm
Color Blue
Number of Positions 19
Type Plug for Unshrouded Header
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Interlocking (Side)
Series TH
Packaging Bulk
Operating Temperature -40°C~115°C
Physical
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 10 Weeks
