KR1301000000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
KR ROHS3Compliant Tin M2.6 Terminal Block Plug for Unshrouded Header 14-26AWG -40C~115C 10A 300V
PDF
/
Inventory: 7349
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Technical
Operating Temperature -40°C~115°C
Packaging Bulk
Series KR
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug for Unshrouded Header
Number of Positions 13
Color Black
Pitch 0.197 5.00mm
Insulation Height 0.512 13.00mm
Termination Style Screw - Leaf Spring, Wire Guard
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 14-26 AWG
Current - UL 10A
Torque - Screw 0.4 Nm (3.5 Lb-In)
Plug Wire Entry 90°
Wire Strip Length 5-6mm
Screw Size M2.6
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
