KD2370520000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
KD ROHS3Compliant Latch Lock Retention Latches (Wire Side) Tin Terminal Block Plug, Female Sockets 14-24AWG -40C~115C 12A 300V
PDF
/
Inventory: 1494
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Technical
Operating Temperature -40°C~115°C
Packaging Bulk
Series KD
Feature Latch Lock, Retention Latches (Wire Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug, Female Sockets
Number of Positions 23
Color Green
Pitch 0.197 5.00mm
Insulation Height 0.429 10.90mm
Termination Style Screwless - Leg Spring, Push-In Spring
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 14-24 AWG
Current - UL 12A
Plug Wire Entry 180°
Wire Strip Length 11-12mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
