HW1610000000G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
HW ROHS3Compliant Tin Phosphor Bronze Terminal Block Plug, Female Sockets 16-28AWG -40C~115C 8A 300V
PDF
/
Inventory: 6819
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Technical
Operating Temperature -40°C~115°C
Packaging Bulk
Series HW
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug, Female Sockets
Number of Positions 16
Color Black
Pitch 0.138 3.50mm
Insulation Height 0.488 12.40mm
Termination Style Screwless - Leg Spring, Push-In Spring
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 16-28 AWG
Current - UL 8A
Plug Wire Entry 180°
Wire Strip Length 9mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
