20020004-D032B01LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
01-381 ROHS3Compliant Right Angle Tin Terminal Block Plug, Female Sockets 26AWG 115C 10A 300V
PDF
/
Inventory: 8110
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Screw Size M2
Number of Positions Per Level 3
Wire Strip Length 6-7mm
Wire Gauge or Range - mm2 0.5-1.5mm2
Plug Wire Entry 180°
Positions Per Level 3
Torque - Screw 0.23 Nm (2.0 Lb-In)
Current - UL 10A
Wire Gauge or Range - AWG 16-26 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 26 AWG
Current 10A
Number of Levels 1
Voltage 300V
Housing Color Black
Number of Contacts 3
Termination Style Screw - Rising Cage Clamp
Current Rating 10.5A
Insulation Height 0.437 11.10mm
Orientation Right Angle
Pitch 0.150 3.81mm
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 115°C
Number of Positions 3
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 01-381
Packaging Bulk
Operating Temperature -40°C~115°C
Physical
Housing Material Thermoplastic Resin
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 10 Weeks
