20020006-H121B01LF
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
12 Position Terminal Block Plug, Female Sockets 0.200" (5.08mm)180° Free Hanging (In-Line)
PDF
/
Buying Options
Total Price: USD $3.84
Unit Price: USD $3.839425
≥1 USD $3.839425
≥10 USD $3.622094
≥100 USD $3.417074
≥500 USD $3.223649
≥1000 USD $3.041181
Inventory: 5708
Minimum: 1
-
+
Technical Details
Physical
Contact Material Steel
Contact Plating Tin
Mount Cable, Free Hanging
Housing Material Thermoplastic
Technical
Packaging Bulk
Termination Screw
ECCN Code EAR99
Max Operating Temperature 115°C
Min Operating Temperature -40°C
Color Green
Number of Rows 1
HTS Code 8536.69.40.40
Pitch 5.08mm
Orientation Right Angle
Depth 15.1mm
Voltage 300V
Number of Levels 1
Current 12A
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 12 AWG
Number of Decks 1
Terminal and Terminal Block Type STRIP TERMINAL BLOCK
Number of Ways 12
Safety Approval UL
Number of Positions Per Level 12
Wire Cross Section 2.5 mm2
Max Supply Voltage (AC) 300V
Dimensions
Length 60.96mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
