20020003-G041B01LF
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Plug
PDF
/
Inventory: 9650
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 30mm
Technical
Max Supply Voltage (AC) 300V
Number of Positions Per Level 4
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 24 AWG
Current 12A
Number of Levels 1
Number of Circuits 4
Voltage 300V
Housing Color Green
Number of Contacts 4
Current Rating 12A
Depth 18.2mm
Orientation Right Angle
Pitch 5.0038mm
Voltage - Rated 300V
Number of Rows 1
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 115°C
Number of Positions 4
Connector Type Terminal Block
Termination Screw
Packaging Bulk
Physical
Housing Material Thermoplastic
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material Bronze
