1792670000
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Din Rail, Channel
Description
STANDARD: UL 94V-0 Din Rail Terminal Block
PDF
/
Inventory: 8775
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Panel
Housing Material Nylon
Material - Insulation Thermoplastic, Wemid
Technical
Published 2009
Series I
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Type Disconnect
Color Blue
Number of Rows 2
Voltage - Rated 6kV
Additional Feature STANDARD: UL 94V-0
HTS Code 8536.69.40.40
Orientation Straight
Current Rating 16A
Termination Style IDC
Approval Agency CE, CSA, IEC, cURus
Voltage 300V
Number of Levels 1
Current 10A
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 16 AWG
Number of Decks 1
Wire Gauge or Range - AWG 16-24 AWG
Voltage - IEC 400V
Number of Ways 2
Safety Approval UL; CSA; CE
Wire Gauge or Range - mm2 0.21-1.5mm2
Current - IEC 16A
Fastening Method IDC
Dimensions
Height 40mm
Length 78.5mm
Width 5.1mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
