1119810000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Din Rail, Channel
Description
Channel Terminal Block
PDF
/
Inventory: 2872
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 11.9mm
Length 60mm
Height 78.5mm
Technical
Disconnect Type Fuse, Removable Plug
Current - IEC 6.3A
Wire Gauge or Range - mm2 0.5-10mm2
Fuse Type 1 1/4 x 1/4
Voltage - IEC 500V
Wire Gauge or Range - AWG 8-22 AWG
Wire Gauge (Min) 8 AWG
Wire Gauge (Max) 22 AWG
Current 10A
Number of Levels 1
Max Supply Voltage 70V
Voltage 600V
Approval Agency CSA, IEC, UR
Termination Style Screw
Current Rating 6.3A
Color Beige
Number of Positions 2
Type Disconnect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature LED
Series W
Published 2012
Physical
Material - Insulation Thermoplastic, Wemid
Supply Chain
Factory Lead Time 10 Weeks
