1018600000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Din Rail, Channel
Description
CONN TERM BLK DISCONNECT 8-20AWG
PDF
/
Buying Options
Total Price: USD $11.96
Unit Price: USD $11.9592
≥1 USD $11.9592
≥10 USD $10.52128
≥100 USD $9.923584
≥500 USD $9.445392
≥1000 USD $9.266048
≥3000 USD $8.07041
Inventory: 35
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Housing Material Nylon
Weight 35.65g
Material - Insulation Thermoplastic, Wemid
Technical
Published 2009
Series W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Type Disconnect
Color Beige
Number of Rows 2
Voltage - Rated 500V
Additional Feature STANDARD: UL 94V-0
HTS Code 8536.69.40.40
Orientation Straight
Current Rating 41A
Termination Style Screw
Approval Agency CE, CSA, UR
Voltage 600V
Number of Levels 1
Current 45A
Wire Gauge (Max) 20 AWG
Wire Gauge (Min) 8 AWG
Number of Decks 1
Wire Gauge or Range - AWG 8-20 AWG
Voltage - IEC 500V
Safety Approval UL; CSA; CE
Wire Gauge or Range - mm2 0.5-10mm2
Current - IEC 41A
Stripping Length 12mm
Disconnect Type Switch, Slide
Dimensions
Height 64mm
Length 87mm
Width 7.9mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
