0590160000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Din Rail, Channel
Description
Conn Feed-Through Terminal Block 4 POS Screw ST Cable Mount 32A
PDF
/
Inventory: 8610
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-2
Dimensions
Terminal Width 6.0mm
Width 6mm
Length 50mm
Height 60.5mm
Technical
Stripping Length 8mm
Wire Gauge or Range - mm2 0.5-4mm2
Safety Approval UL; CSA; CE
Voltage - IEC 500V
Wire Gauge or Range - AWG 12-26 AWG
Number of Decks 2
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 26 AWG
Current 27A
Number of Levels 2
Max Current Rating 32A
Voltage 300V
Approval Agency CE, CSA, IEC, UR
Termination Style Screw
Current Rating 32A
Depth 6mm
Orientation Straight
Voltage - Rated 6kV
Number of Rows 4
Color Beige
Min Operating Temperature -50°C
Max Operating Temperature 100°C
Type Feed Through
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series SAK
Physical
Material - Insulation Polyamide (PA66), Nylon 6/6
Housing Material Polyamide
Material Nylon
Mount Cable
Supply Chain
Factory Lead Time 8 Weeks
