0128320000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Din Rail, Channel
Description
CONN TERM BLK FEED THRU 10-26AWG
PDF
/
Inventory: 9276
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Cable
Housing Material Plastic
Weight 14.02g
Material - Insulation Gemin (Thermosetting Plastic)
Technical
Series SAK
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Feed Through
Max Operating Temperature 130°C
Min Operating Temperature -60°C
Color Yellow
Number of Rows 2
Voltage - Rated 8kV
Additional Feature POLYAMIDE
HTS Code 8536.69.40.40
Current Rating 32A
Termination Style Screw
Approval Agency CE, CSA, IEC, UR
Housing Color Beige
Voltage 600V
Max Current Rating 30A
Number of Levels 1
Current 28A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 10 AWG
Voltage - UL 600V
Number of Decks 1
Wire Gauge or Range - AWG 10-26 AWG
Current - UL 30A
Voltage - IEC 800V
Number of Ways 2
Safety Approval UL; CSA; CE
Wire Gauge or Range - mm2 0.5-6mm2
Stripping Length 12mm
Dimensions
Height 51.5mm
Length 40mm
Width 6.5mm
Compliance
Material Flammability Rating UL94 5VA
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 5VA
Lead Free Lead Free
