CGMT4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Din Rail, Channel
Description
DIN Rail Terminal Blocks Mini Feed-thru Term
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.4112
≥1 USD $2.4112
≥10 USD $1.83656
≥100 USD $1.720224
≥500 USD $1.529088
≥1000 USD $1.495736
≥3000 USD $1.462982
Inventory: 911
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Housing Material Polyamide
Material - Insulation Polyamide (PA66), Nylon 6/6
Technical
Published 2003
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Ground, Earth
Number of Positions 2
Color Green, Yellow
Voltage - Rated 400V
Current Rating 32A
Termination Style Screw
Number of Levels 1
Wire Gauge (Max) 10 AWG
Wire Gauge (Min) 22 AWG
Wire/Cable Gauge 12 AWG
Voltage - UL 300V
Wire Gauge or Range - AWG 10-22 AWG
Voltage - IEC 500V
Wire Gauge or Range - mm2 0.2-4mm2
Stripping Length 8mm
Dimensions
Height 28.5mm
Length 27mm
Width 6mm
Terminal Width 6.0mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
