1546700-8 image
Favorite
1546700-8 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description CONN BARRIER STRP 22CIRC 0.375"
PDF
/
Inventory: 8777
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Mount Panel
Mounting Type Chassis, Panel
Material - Insulation Thermoplastic
Terminal Screw Material Steel

Technical

Operating Temperature 105°C
Packaging Bulk
Published 2007
Series JC6, Buchanan
Feature Flange
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Faston
ECCN Code EAR99
Color Black
Number of Rows 1
HTS Code 8536.69.40.40
Pitch 0.375 9.53mm
Orientation Straight
Current Rating 20A
Wire Gauge 12-22 AWG
Voltage 300V
ELV Compliant
Number of Circuits 22
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 12 AWG
Terminal Block Type Barrier Block
Bottom Termination Quick Connect (0.250), Insulated
Barrier Type 2 Wall (Dual)
Top Termination Screws
Terminal Screw Finish Zinc, Clear Chromate

Dimensions

Length 201.9231mm

Compliance

Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
