8-796602-7
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
Terminal Barrier Block
PDF
/
Inventory: 5851
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 147.62mm
Technical
Number of Wire Entries 11
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 22 AWG
Number of Levels 1
Number of Circuits 11
Voltage 600V
Housing Color Black
Number of Contacts 11
Current Rating 20A
Orientation Straight
Pitch 11.1mm
Voltage - Rated 600V
Number of Rows 1
Color Black
Min Operating Temperature -60°C
Max Operating Temperature 105°C
Number of Positions 11
Termination Solder
Packaging Bulk
Physical
Terminal Material Brass
Housing Material Nylon
Insulation Material Nylon
Mount Chassis, Panel, Through Hole
