2-1546725-1
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
Terminal Barrier Block
PDF
/
Inventory: 4909
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Steel
Contact Plating Tin
Mount Panel
Housing Material Thermoplastic
Technical
Packaging Bulk
Termination Solder
Number of Positions 21
Color Black
Number of Rows 1
Pitch 9.53mm
Orientation Straight
Depth 16mm
Current Rating 20A
Number of Contacts 21
Housing Color Black
Voltage 300V
ELV Compliant
Number of Circuits 21
Max Supply Voltage 300V
Number of Levels 1
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 12 AWG
Current Rating (Max) 20A
Dimensions
Length 217.526mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
