2-1546720-7

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description Barrier Terminal Blocks JC6-E107-15-182 JC6 ASSEMBLY
PDF
/
Inventory: 9755
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Radiation Hardening No

Dimensions

Length 144.4244mm

Technical

Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 22 AWG
Number of Levels 1
Max Supply Voltage 300V
Number of Circuits 15
ELV Compliant
Voltage 300V
Current Rating 20A
Depth 16mm
Orientation Straight
Pitch 9.53mm
HTS Code 8536.69.40.40
Voltage - Rated 300V
Color Black
ECCN Code EAR99
Termination Solder
Part Status Discontinued
Published 2007
Packaging Bulk

Physical

Housing Material Thermoplastic
Mount Through Hole
Contact Plating Tin
Contact Material Steel

Supply Chain

Factory Lead Time 21 Weeks
