2-1546700-9

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description Terminal Barrier Block
PDF
/
Inventory: 2643
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Length 106.3244mm

Technical

Number of Wire Entries 11
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 22 AWG
Number of Levels 1
Number of Circuits 11
ELV Compliant
Voltage 300V
Housing Color Black
Number of Contacts 11
Current Rating 20A
Depth 36.32mm
Orientation Straight
Pitch 9.53mm
Voltage - Rated 300V
Number of Rows 1
Color Black
Number of Positions 11
Termination Faston
Packaging Bulk

Physical

Housing Material Thermoplastic
Insulation Material Thermoplastic
Mount Panel
Contact Plating Tin
Contact Material Steel

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
